Airtac 7V Solenoid Valve 7V0510J04C200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510J04C200 Solenoid Valve Technical Details
- Model: 7V0510J04C200
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: ≤2.2W (DC), ≤3.5VA (AC)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5MPa)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Body material: Reinforced PBT with brass inserts
- Protection class: IP67 (dust/water resistant)
- Weight: 320g ±5g (including coil)
- Dimensions: 70mm(L) × 45mm(W) × 100mm(H)
- Port thread depth: 12mm (minimum engagement)
- Max cycling rate: 5Hz (300 cycles/minute)
High-flow directional control valve featuring optimized spool geometry for reduced pressure drop. The 7V series employs a pilot-assisted operation mechanism requiring only 0.15MPa minimum operating pressure. Enhanced with arc suppression circuits in the coil for extended electrical life (>10 million cycles).
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery clamp controls
- Automated material handling systems
- Plastic injection molding machine actuators
- Semiconductor wafer handling robotics
Installation guidelines:
Mount in vibration-free locations using M4 mounting screws (max torque 1.2N·m).
Maintain ambient temperature below 60℃ with 20mm clearance for heat dissipation.
Use 5-40μm filtration with automatic drain lubricators (ISO 8573-1:2010 Class 4).
Critical note:
Do not apply silicone-based lubricants - use ISO VG32 turbine oil only.
Manual override requires 3N·m rotational force (emergency use only).
| Property | Property Value |
|---|---|
| sku | 7V0510J04C200 |
| Port Size | PT 1/2 |
| Standard Voltage | AC 110V |
