Airtac 7V Solenoid Valve 7V0510J04F050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510J04F050 Solenoid Valve Specifications
- Model: 7V0510J04F050
- Type: 5/2-way single solenoid (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 750 L/min (ANR)
- Response time: ≤15ms (at 0.5 MPa)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature range: -5℃ to 80℃
- Protection rating: IP67 (dustproof and waterproof)
- Weight: 480g ±5%
- Dimensions: 118mm(L) × 42mm(W) × 60mm(H)
- Port thread depth: 12mm (minimum engagement)
- Manual override: Built-in emergency button
High-flow directional control valve with metal seal option, engineered for industrial automation systems requiring rapid cycling. Features low-hysteresis spool design and surge suppression for stable operation in high-vibration environments. Compatible with ISO 15407-1 standards. Requires 5μm filtered dry air with oil mist ≤1mg/m³.
- Plastic injection molding machine clamp control
- Automated assembly line actuators
- Textile machinery cylinder sequencing
- Beverage filling system pneumatic circuits
- Semiconductor handling equipment
Installation guidelines:
Mount in any orientation (horizontal/vertical) with vibration dampening pads.
Maintain 15mm clearance around coil for heat dissipation. Use shielded cables
for electrical connections in EMI-sensitive environments. Lubricate sliding
parts with ISO VG32 turbine oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 7V0510J04F050 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
