Airtac 7V Solenoid Valve 7V0510M5A200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5A200 Solenoid Valve Technical Details
- Model: 7V0510M5A200
- Valve type: 5/2-way single solenoid (monostable)
- Port configuration: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow capacity: 850 L/min (Cv=1.2 at 0.5MPa)
- Response time: ≤25ms (exhaust to actuation)
- Duty cycle: 100% continuous operation capable
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Protection class: IP67 (dust-tight & protected against temporary immersion)
- Weight: 320g ±5g (including coil and connector)
- Dimensions: 56mm(W) × 38mm(H) × 98mm(L)
- Port thread depth: 10mm minimum engagement
High-flow directional control valve with compact profile, featuring manual override and LED status indicator. The aluminum alloy body with hard anodizing treatment ensures durability in humid environments. Optimized flow path design reduces pressure drop by 15% compared to previous generation models.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery clamp control systems
- Plastic injection molding machine ejectors
- Automated warehouse stacking robots
- Food processing pneumatic circuits (requires food-grade lubrication)
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 20mm clearance below valve for condensate drainage.
Use PTFE tape on port threads with clockwise wrapping direction.
| Property | Property Value |
|---|---|
| sku | 7V0510M5A200 |
| Port Size | M5 |
| Standard Voltage | AC220V |
