Airtac 7V Solenoid Valve 7V0510M5B050
Genuine AirTAC solenoid valve, order code 7V0510M5B050 from the 7V0510 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- PortM5
- Coil voltageDC24V (B)
- Lead wireLead 0.5 m (050)
- Function5/2-way single solenoid (single solenoid, spring return)
- PortsM5, Ø4 mm push-in (J04)
- Effective area3.4 mm² (Cv 0.2) on M5
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac 7V Solenoid Valve 7V0510M5B050
Built on the 7V0500 body, the AirTAC 7V0510M5B050 is a 5/2-way single-solenoid valve with M5 supply, outlet and exhaust ports. Energizing the coil shifts the spool and a spring returns it when the power is off. The catalog flow on M5 is 3.4 mm2 (Cv 0.2). The DC24V coil (code B) draws 0.7 W, is class F and dust-protected, responds in 0.05 s or less and plugs in horizontally or vertically; the 050 code gives a 0.5 m lead.
It is pilot operated from 0.15 to 0.8 MPa (21-114 psi) on air filtered to 40 um, proof pressure 1.2 MPa, -10 to +50 C, at up to 5 cycles/s, and weighs 30 g. The die-cast aluminum-alloy body collects the pilot exhaust and vents it through the R and S ports. No lubrication is needed; once lubricated air is used, keep using it with ISO VG32 oil.
Airtac 7V Solenoid Valve 7V0510M5B050 Technical Specifications
| Order code | 7V0510M5B050 |
|---|---|
| Product | Solenoid Valve |
| Port | M5 |
| Coil voltage | DC24V (B) |
| Lead wire | Lead 0.5 m (050) |
| Function | 5/2-way single solenoid (single solenoid, spring return) |
|---|---|
| Ports | M5, Ø4 mm push-in (J04) |
| Effective area | 3.4 mm² (Cv 0.2) on M5 |
| Weight | 30 g |
| Max frequency | 5 cycles/s |
| Fluid | Air (filtered by 40 µm element) |
| Pilot | Internal |
| Operating pressure | 0.15 – 0.8 MPa (21 – 114 psi) |
| Proof pressure | 1.2 MPa (175 psi) |
| Temperature | -10 to +50 °C |
| Coil power | AC 1.1 VA · DC 0.7 W |
| Voltage tolerance | AC +15% / -10%, DC ±10% |
| Insulation | Class F, dust-protected |
| Body | Aluminum alloy |
| Lubrication | Not required |
Source: AirTAC catalog P80, 7V series specifications and ordering code. Effective area is the catalog figure for the M5 port.
How to choose
Within the 7V0510, AC220V, AC110V and DC12V coils replace the B with A/C/F; 7V0510M5B200 has the 2.0 m lead; the other ports of this body are Dia 4 mm push-in (7V0510J04B050). The same body comes as 7V0520, 7V0530C, 7V0530E and 7V0530P: 10 single solenoid, 20 double solenoid, 30C/30E/30P the 5/3-way centers. Several 7V0500 valves can share a 7V0500M manifold base of 1 to 20 stations.
Applications
Spring-return cylinder control
A 24 V DC PLC output switches a double-acting cylinder; with the coil off the spring returns it to the start position.
Machine pneumatics
Cv 0.2 on M5 suits small cylinders and pilot lines in tight spaces.
DC24V control circuits
The DC24V coil connects to a 24 V DC PLC output; the 0.5 m lead plugs into the coil terminal.
FAQ
What are the key figures of the 7V0510M5B050?
5/2-way single-solenoid valve, 7V0500 series; M5 ports; catalog flow 3.4 mm2 (Cv 0.2); 0.15-0.8 MPa (21-114 psi), proof 1.2 MPa; -10 to +50 C; up to 5 cycles/s; DC24V coil, 0.7 W, class F; 0.5 m lead; response 0.05 s or less; 30 g.
What does the 7V0510M5B050 do with the coil off?
Energizing the coil shifts the spool and a spring returns it when the power is off.
