Airtac 7V Solenoid Valve 7V0510M5B200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5B200 5/2-Way Solenoid Valve Specifications
- Model: 7V0510M5B200 (M5 coil connector variant)
- Type: 5/2-way single solenoid pilot-operated
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Response time: ≤20ms (exhaust to operation)
- Weight: 320g ±5% (without accessories)
- Dimensions: 80mm(L) × 40mm(W) × 72mm(H)
- Valve body material: Aluminum alloy with hard anodized finish
- Seal material: NBR (Nitrile rubber) standard, optional FKM/Viton
- Temperature range: -5℃ to 80℃ (operating fluid), -20℃ to 60℃ (ambient)
- Power consumption: 2.2W (DC24V), 3.5VA (AC)
- Protection rating: IP65 (coil), IP40 (valve body)
- Manual override: Built-in emergency push button
- Mounting style: Direct mounting with ISO 15407-1 compliant interface
High-flow 5/2 directional control valve featuring dual-pressure operation capability and low power consumption design. The hardened aluminum construction provides excellent heat dissipation, while the M5 quick-connect terminals enable tool-free wiring. Optimized flow paths reduce pressure drop by 15% compared to previous generation models.
- Double-acting cylinder control in automated assembly lines
- Pneumatic clamping systems for CNC machinery
- Material handling equipment (conveyor diverters/lifters)
- Textile machinery tension control systems
- Plastic injection molding machine ejectors
Installation guidelines:
Maintain horizontal mounting position for optimal seal life. Use a 5μm filter with auto-drain and lubricator (F.R.L. unit) upstream. For multi-valve manifolds, limit stack height to 20 units maximum. Allow 50mm clearance below for tubing connections.
| Property | Property Value |
|---|---|
| sku | 7V0510M5B200 |
| Port Size | M5 |
| Standard Voltage | DC24V |
