Airtac 7V Solenoid Valve 7V0510M5C050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5C050 Solenoid Valve Specifications
- Model: 7V0510M5C050
- Type: 5/2-way single solenoid pilot-operated (spring return)
- Port size: M5 threaded connection
- Port configuration: 5 ports (P: pressure, A/B: outlets, R/S: exhausts)
- Operating pressure: 0.1–0.9 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 450 l/min (ANR)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Weight: 220g ±5g
- Dimensions: 54mm(L) × 40mm(W) × 65mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (with 1% lubricant)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 9mm (recommended engagement)
High-flow 5/2-way valve with dual exhaust ports, engineered for rapid cycling applications requiring precise directional control. Features copper-free aluminum alloy body with hard anodized coating for corrosion resistance. Includes manual override and LED status indicator. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Industrial automation sequencing systems
- Textile machinery cylinder control
- Plastic injection molding ejectors
- Food processing pneumatic actuators
- Automotive assembly line tooling
Installation note:
Mount in vibration-free environment using M5 mounting brackets (max torque 1.2Nm).
Maintain horizontal piping alignment and install silencers if exhaust noise exceeds 75dB(A).
Critical parameters:
- Max allowable leakage: 30 cm³/min at 0.5MPa
- Coil insulation class: F (155℃)
- Lubrication interval: 20 million cycles (dry air) / 50 million (lubricated)
| Property | Property Value |
|---|---|
| sku | 7V0510M5C050 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
