Airtac 7V Solenoid Valve 7V0510M5C200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0510M5C200 Solenoid Valve Specifications
- Model: 7V0510M5C200
- Type: 5/2-way monostable (spring return)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V/120V (50/60Hz), AC220V/240V (50/60Hz)
- Weight: 280g ±5g (without connector)
- Dimensions: 53mm(L) × 35mm(W) × 76mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (with dry air)
- Power consumption: 2.2W (DC) / 3.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Port thread depth: 10mm (minimum engagement)
- Protection rating: IP67 (dust/water resistant)
- Expected service life: 50 million cycles (under rated conditions)
High-flow 5-port directional valve with manual override, featuring optimized flow paths achieving Cv=0.48. The anodized aluminum body with brass ports ensures corrosion resistance in humid environments. Includes LED status indicator and surge protection circuit. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Multi-axis pneumatic cylinder control systems
- Textile machinery sequencing operations
- Bottle cap tightening/loosening mechanisms
- Semiconductor wafer handling robots
- Automotive assembly line tooling
Installation note:
For optimal performance, maintain ambient temperature below 60℃ and install with
vibration-damping mounts in high-shock environments. Allow minimum 20mm clearance
below valve for exhaust airflow. Use M5x0.8 mounting screws with 0.6-0.8Nm torque.
| Property | Property Value |
|---|---|
| sku | 7V0510M5C200 |
| Port Size | M5 |
| Standard Voltage | AC 110V |
