Airtac 7V Solenoid Valve 7V0520J04A050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520J04A050 Solenoid Valve Specifications
- Model: 7V0520J04A050
- Type: 5-port, 2-position (5/2-way) direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (including coil)
- Dimensions: 78mm(L) × 54mm(W) × 53mm(H)
- Flow coefficient (Cv): 1.4
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with 5℃ safety margin)
- Power consumption: DC24V/2.5W, AC110V/4.8VA, AC220V/5.5VA
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Protection rating: IP65 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with manual override, designed for precision pneumatic systems requiring rapid cycling. Features copper-free aluminum alloy body with hard anodized treatment for corrosion resistance. The low-hysteresis coil design ensures stable operation under voltage fluctuations (±10% tolerance). Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Automated production line actuators
- Plastic injection molding machines
- Packaging machinery clamp control
- Semiconductor wafer handling systems
- Automotive assembly line tooling
- Food processing equipment (oil-resistant version available)
Installation note:
Maintain horizontal mounting orientation for optimal drainage.
Use M5 mounting screws with 45-50 kgf·cm torque. Allow 15mm
clearance below valve for maintenance access. Lubricate seals
with ISO VG32 turbine oil during assembly.
| Property | Property Value |
|---|---|
| sku | 7V0520J04A050 |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
