Airtac 7V Solenoid Valve 7V0520J04B050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520J04B050 Solenoid Valve Technical Details
- Model: 7V0520J04B050
- Type: 5/2-way single solenoid (spring return)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 850 L/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W / AC: 4.5VA
- Response time: ≤15ms (exhaust to actuation)
- Seal material: Heat-resistant NBR (-20℃ to 80℃)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
- Weight: 310g ±5g (including coil)
- Dimensions: 58mm(L) × 36mm(W) × 78mm(H)
- Manual override: Built-in emergency button
- Service life: ≥10 million cycles (at rated conditions)
High-flow solenoid valve with integrated silencer, featuring optimized spool geometry for reduced pressure drop. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Designed for ISO 15407-1 compliance, it supports pulse-width modulation (PWM) control for energy efficiency.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery air circuit control
- Automated sorting systems with rapid cycling
- Plastic injection molding machine actuators
- Food processing equipment (oil/moisture-resistant version available)
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (torque ≤0.8Nm).
Maintain 15mm clearance from heat sources. Use air dryer when relative humidity exceeds 80%.
Lubricate with ISO VG32 turbine oil if pneumatic system lacks lubrication.
| Property | Property Value |
|---|---|
| sku | 7V0520J04B050 |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
