Airtac 7V Solenoid Valve 7V0520J04C200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520J04C200 Solenoid Valve Specifications
- Model: 7V0520J04C200
- Type: 5/2-way dual solenoid (with manual override)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 1.8W per solenoid (Class F insulation)
- Flow capacity: 850 l/min (Cv=1.3 at 0.5 MPa)
- Weight: 450g ±5% (with mounting bracket)
- Dimensions: 80mm(L) × 40mm(W) × 120mm(H)
- Seal material: Heat-resistant NBR (replaceable cartridge design)
- Temperature range: -5℃ to 60℃ (fluid temperature)
- Response time: ≤15ms (at rated pressure)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Service life: ≥10 million cycles (at max operating conditions)
High-flow proportional solenoid valve with dual-coil latching design, featuring dust-tight construction and manual override for emergency operation. The aluminum alloy body with hard anodized finish ensures corrosion resistance in humid environments. Includes LED status indicator and surge protection circuit.
- Automated packaging line cylinder control
- Injection molding machine clamp systems
- Material handling equipment actuators
- Automotive assembly line robotics
- Food processing pneumatic circuits (FDA-compliant grease option available)
Installation guidelines:
Install downstream of 5μm filter regulator. Maintain ambient temperature below coil's rated maximum.
For dual voltage models, ensure proper jumper configuration. Allow 20mm clearance above valve for manual override operation.
| Property | Property Value |
|---|---|
| sku | 7V0520J04C200 |
| Port Size | PT 1/2 |
| Standard Voltage | AC 110V |
