Airtac 7V Solenoid Valve 7V0520J04F200
$45.35
Regular price
$52.85
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
7V0520J04F200
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Plug-in terminal connection design allows horizontal and vertical orientations to be freely interchangeable;
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
Installation guidelines:
Mount in vibration-free environment using M4 screws (torque ≤0.8N·m).
Maintain minimum 20mm clearance for heat dissipation. Lubricate seals
quarterly in high-cycle applications (>500k operations/month).
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520J04F200 Solenoid Valve Technical Details
- Model: 7V0520J04F200 (7V series, 5-way)
- Valve type: 5/2-way single solenoid (monostable)
- Port configuration: G1/4 (ISO standard)
- Operating pressure range: 0.1–0.7 MPa (14.5–101.5 PSI)
- Voltage variants: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Manual override: Optional with lockable button
- Flow capacity: 850 l/min (Cv=1.2 at 0.5 MPa)
- Weight: 310g ±5g (including coil)
- Dimensions: 60mm(L) × 40mm(W) × 82mm(H)
- Seal materials: NBR standard (option: FKM/Viton)
- Ambient temperature: -10℃ to 60℃ (14℉ to 140℉)
- Response time: ≤25ms (at rated voltage)
- Protection class: IP67 (dustproof & temporary immersion)
- Electrical connection: DIN43650 Form A (standard)
High-flow 5-port pneumatic valve with low power consumption design (3.5W max), featuring brass body construction with hard anodized aluminum core. Includes LED status indicator and surge protection circuitry. Requires 5μm filtered compressed air (lubricated or non-lubricated).
Industrial Applications:
- Double-acting cylinder control in automation lines
- Pneumatic clamping systems for CNC machinery
- Packaging equipment sequencing valves
- Automotive tire inflation systems
- Bottle cap sorting machines
Installation guidelines:
Mount in vibration-free environment using M4 screws (torque ≤0.8N·m).
Maintain minimum 20mm clearance for heat dissipation. Lubricate seals
quarterly in high-cycle applications (>500k operations/month).
| Property | Property Value |
|---|---|
| sku | 7V0520J04F200 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
