Airtac 7V Solenoid Valve 7V0520M5A050
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520M5A050 Solenoid Valve Technical Specifications
- Model: 7V0520M5A050 (7V Series)
- Valve type: 5/2-way monostable (single solenoid)
- Port configuration: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage specifications: DC24V (±10%)
- Coil power: 1.6W (Class F insulation)
- Response time: ≤20ms (at rated voltage)
- Flow capacity: CV 0.25 (Kv 0.22)
- Seal material: Heat-resistant NBR (-20℃ to 100℃)
- Valve body material: Aluminum alloy (anodized surface)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 9.5mm (minimum engagement)
- Weight: 220g ±5% (excluding connector)
- Dimensions: 60mm(L) × 40mm(W) × 75mm(H)
High-performance 5-port pneumatic valve featuring low power consumption and fast switching capability. The 7V series incorporates a manual override function with lockable actuator for maintenance operations. Optimized flow path design reduces pressure drop by 15% compared to previous generations. Requires ISO 8573-1 class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping systems
- Textile machinery cylinder control
- Plastic injection molding ejectors
- CNC machine tool chuck actuators
- Bottle capping machine sequencing
Installation guidelines:
Mount with M5 screws (recommended torque 1.2N·m). Maintain minimum 50mm
clearance below valve for tubing connections. Use 18-24AWG wiring
with crimp terminals. Perform monthly air filter drain checks.
| Property | Property Value |
|---|---|
| sku | 7V0520M5A050 |
| Port Size | M5 |
| Standard Voltage | AC220V |
