Airtac 7V Solenoid Valve 7V0520M5A200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520M5A200 Solenoid Valve Specifications
- Model: 7V0520M5A200
- Type: 5/2-way single solenoid pilot-operated (monostable)
- Port size: M5 (ISO G1/8 thread equivalent)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 220g ±5g (without connector)
- Dimensions: 60mm(L) × 40mm(W) × 30mm(H)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (no freezing)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤20ms (at 0.5MPa)
- Flow coefficient (Cv): 0.15
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhausts)
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Optional paddle-type
- Housing material: Reinforced PBT resin (coil), Aluminum alloy (valve)
High-speed 5-port directional valve with compact modular design, featuring optimized flow paths for reduced pressure drop. The corrosion-resistant aluminum body and shielded coil enable reliable operation in humid/vibratory environments. Requires ISO 8573-1 class 3 compressed air (max 5μm particle size, 0.1mg/m³ oil content).
- Pneumatic cylinder sequencing in automated assembly lines
- Clamping/unclamping mechanisms in CNC machinery
- Vacuum generator control in packaging systems
- Medical bed articulation systems
- Semiconductor wafer handling robots
Installation note:
Mount using M5 screws with 0.8Nm torque. For horizontal mounting,
orient exhaust ports downward to prevent debris accumulation.
Use surge protection circuit for AC coils in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 7V0520M5A200 |
| Port Size | M5 |
| Standard Voltage | AC220V |
