Airtac 7V Solenoid Valve 7V0520M5B200
2. Internal exhaust structure collects pilot gas and discharges centrally through R/S ports;
3. Aluminum alloy die-casting body with optimized flow path design enhances flow capacity;
4. Available in threaded or quick-connect versions, compatible with manifold base integration for space-saving installation.
Category: Solenoid Valves, Brand: Airtac, Series: 7V
AirTAC 7V0520M5B200 Solenoid Valve Technical Details
- Model: 7V0520M5B200 (7V series, M5 thread variant)
- Valve type: 5/2-way monostable (single solenoid)
- Operation: Internal pilot operated
- Port size: M5 (ISO G1/8 equivalent flow)
- Effective area: 20mm² (critical for response time calculation)
- Operating pressure range: 0.1-0.8 MPa (14.5-116 PSI)
- Voltage variants: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Coil insulation class: Class F (155℃ max)
- Response time: ≤20ms (pressure-dependent)
- Weight: 180g ±5% (including coil assembly)
- Dimensions: 52mm(L) × 42mm(W) × 30mm(H) (body only)
- Seal material: HNBR (hydrogenated nitrile) for improved oil resistance
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Power consumption: 2.2W (DC24V), 3.5VA (AC)
- Protection standard: IP67 (dust/water resistant)
- Port thread torque: 0.8-1.2 N·m (M5 port tightening specification)
High-flow micro-valve with integrated silencer, designed for precision directional control in compact automation systems. Features copper-free aluminum alloy construction for food/pharma compatibility and reduced galvanic corrosion. Requires 5μm filtration with ISO 8573-1:2010 Class 3 air quality.
- PCB handling robotic end-effectors
- IVD medical analyzer reagent dispensing
- Semiconductor wafer clamping systems
- High-cycle packaging machine actuators
- Lithium battery formation equipment
Mounting protocol:
For horizontal piping layouts, install valve within ±5° of specified orientation.
Use anti-vibration washers in applications exceeding 15Hz mechanical resonance.
| Property | Property Value |
|---|---|
| sku | 7V0520M5B200 |
| Port Size | M5 |
| Standard Voltage | DC24V |
