This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACEJ12X100-30SB, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB
The AirTAC ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB is a double acting, double rod, adjustable stroke DIN-standard tight/compact air cylinder with a Ø12mm bore and 100mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACEJ12X100-30SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod, adjustable stroke
- Rod threadM3×0.5
- StatusDiscontinued → ACEJ12X100-30SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB
This ACPJ12X100-30SB is a discontinued double acting compact cylinder with an adjustable extend stroke: a stop screw trims the 100 mm stroke by up to 30 mm, giving a usable range of 70-100 mm. The 12 mm bore delivers 56.5 N push and 42.4 N pull at 0.5 MPa, rising to 79.2 N push at 0.7 MPa. Its 100 mm stroke exceeds the 50 mm standard maximum for this bore, so it is a made-to-order build. The -S magnet is fitted, so CMSE or DMSE switches can be mounted for end-of-stroke signalling.
The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it suits slim jigs and guarded assemblies. A fixed TPU bumper sits at both ends, and the hard-anodized aluminium body carries an S45C hard-chrome rod with a male thread (B code). For sizing: the push force supports about 34 N of real work at 0.5 MPa, roughly a 2.9 kg vertical lift with a 2:1 margin. Production has ended - the current drop-in is ACEJ12X100, but confirm ISO 21287 mounting dimensions before swapping since the ACP is DIN-standard.
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB Technical Specifications
| Model | Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB |
|---|---|
| Series | ACPJ DIN compact cylinder (discontinued) |
| Replacement | ACEJ12X100-30SB |
| Bore size | Ø12 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACEJ12X100-30SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 42 N |
| 0.7 MPa | 59 N |
| Max (@1.0 MPa) | 9 kgf |
ACPJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
Model Code: Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB
| ACPJ | DIN compact cylinder (adjustable-stroke, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -30 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB Is Used
Small-part ejection on assembly fixtures
The 70-100 mm adjustable range lets a fixture builder trim the extend stroke so a 6 mm rod ejects a bushing or pin exactly to a nest, with about 34 N of usable push at 0.5 MPa.
Position-signalled test stations
With the -S magnet fitted, CMSE or DMSE switches confirm rod position on a leak-test or go/no-go gauge station, cycling at 30-500 mm/s within the 70-100 mm window.
Compact clamping inside guarded cells
A body about 50% shorter than an ISO 15552 profile cylinder fits tight gantry brackets, pressing light plastic housings with up to 79.2 N at 0.7 MPa.
Replacing the Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB with the ACEJ12X100-30SB
At 12 mm bore this is the smallest ACPJ size: 56.5 N push at 0.5 MPa versus 100.5 N for the 16 mm and 157.1 N for the 20 mm. If your load needs more than about 34 N of usable force, step up a bore. The 30 mm window only shortens the extend stroke - it is a mechanical stop, not a mid-stroke lock, so the rod can drift if air is lost. FA/FB flange or LB foot mounts bolt to the standard face, and the fitted -S magnet accepts CMSE / DMSE switches. Order the ACEJ12X100 as the current-production replacement.
Replacement checklist
- ✓ Current-production ACE → ACEJ12X100-30SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACPJ Adjustable Compact Cylinder ACPJ12X100-30SB FAQ
At 0.5 MPa it pushes 56.5 N and pulls 42.4 N; at 0.7 MPa that rises to 79.2 N push and 59.4 N pull, with a theoretical maximum of 11.5 kgf at 1.0 MPa. It is double acting, runs on 0.15-1.0 MPa (22-145 psi) filtered air, moves at 30-500 mm/s, and the stop screw trims the 100 mm stroke by up to 30 mm (70-100 mm usable). Note the 100 mm stroke is made to order - the standard maximum for a 12 mm bore is 50 mm.
AirTAC no longer produces the ACPJ family. The current drop-in is the ACEJ12X100 (swap the P for an E), an ISO 21287 adjustable-stroke cylinder in the same 12 mm bore, 100 mm stroke and force class. Before swapping, confirm the ISO 21287 mounting dimensions, because the ACP was built to a DIN-standard footprint. The male rod thread, M5x0.8 port and optional -S magnet concept carry over, but verify the fixture interface.
