AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B

The AirTAC ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø32mm bore and 100mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ32 mm
  • Full stroke100 mm
  • Port sizePT1/8
  • Adjuster threadM12×1.25
$58.12 $65.62Save 11% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every ACQJ32 stroke, mounting and version on one page All ACQJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B

The AirTAC ACQJ32X100-100B is a double-acting JIS compact cylinder featuring an external threaded stop with a lock nut that limits the extend end position. You can fine-tune the usable extend range from 0 mm up to the full 100 mm directly on the machine. The retract stroke remains completely unaffected by this adjustment. This unit includes a male M14x1.5 piston rod end for direct load coupling and utilizes a PT1/8 port.

The cylinder body incorporates sensor grooves for reed or solid-state switches, though this specific configuration ships without a magnet. Deceleration is handled by a fixed NBR elastomer bumper at each end rather than an adjustable air cushion.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B Technical Specifications

ModelAirtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ32 mm
Full stroke100 mm
Adjuster threadM12×1.25
Port sizePT1/8
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM8×1.25 (F) / M14×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa302 N302 N
0.7 MPa422 N—
Max (@1.0 MPa)62 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
32Bore size in mm.
×100Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).

Where the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B Is Used

precision_manufacturing

CNC Fixture Depth Tuning

Dial in the exact clamping depth on a CNC machining fixture during setup, allowing rapid accommodation of varying part heights without swapping out cylinder hardware.

sync_alt

Packaging Line Changeover

Modify the extend stroke on a packaging conveyor diverter to handle different carton sizes, using the external stop to set new end positions quickly.

science

Assembly Press Prototyping

Establish trial end positions for a press operation in electronics assembly, safely testing different engagement distances before finalizing the mechanical stops.

Is the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B the Right Cylinder?

When sizing this actuator, note that dropping to a 25 mm bore reduces the 0.5 MPa push force to 245.4 N, while stepping up to a 40 mm bore increases it to 628.3 N. If your application never requires altering the end position, a fixed-stroke ACQ cylinder will accomplish the same task. To order this adjustable version correctly, confirm the 32 mm bore, the 100 mm full stroke, the 100 mm adjustment window, the male M14x1.5 rod thread, and the absence of the -S magnet option.

Quick checklist

  • ✓ Need on-machine end-position tuning?
  • ✓ Full stroke and adjust window (mm)
  • ✓ Force at your working pressure
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the adjuster nut after setting the stop.
  • check The stop limits the EXTEND stroke only.
  • check Avoid side load on the short piston rod.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-100B FAQ

The usable extend range is 0 to 100 mm, set via the 100 mm adjustment window, while the retract stroke remains fixed at the full 100 mm.

The external M12x1.25 threaded stop with lock nut mechanically limits how far the rod extends, shortening the stroke length without changing the piston area, so the output force remains identical to a standard ACQ. The fixed NBR elastomer bumper decelerates the load near the stroke end, but a plain ACQ cylinder will not hold its load on air loss; for fail-safe holding, an external rod lock is required.
