Airtac ATE Single Acting Guided Compact Cylinder ATE12X5B
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE12X5B Single-Acting Compact Cylinder Specifications
- Model: ATE12X5B
- Type: Single-acting spring return (pull type)
- Bore size: 12mm
- Stroke: 5mm (customizable up to 100mm)
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (standard) / PT1/8 optional
- Cushioning: Adjustable rubber buffer
- Mounting style: Front flange / Foot mounting (ISO 6432 compliant)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.18kg (excluding accessories)
- Dimensions: 60mm(L) × 20mm(W) × 40mm(H) (at full retraction)
- Protection rating: IP40 (standard) / IP67 with optional rod cover
- Max theoretical force: 11.3N at 0.6MPa
- Speed range: 50–700mm/s
Ultra-compact cylinder optimized for space-constrained linear motion applications. Features precision-machined guides for smooth operation and dual adjustable cushions to minimize end-impact noise. The corrosion-resistant construction and ISO-standard mounting patterns enable seamless integration with automation equipment. Requires 40μm filtered air and regular lubrication (ISO VG32 recommended).
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in CNC tool changers
- Valve actuation in medical analyzers
- Paper feed systems in compact printers
- Packaging machine ejector mechanisms
Installation note:
Maintain ≥0.5mm radial clearance around rod when designing mounts. For vertical installations,
use in "rod down" position to prevent seal wear from gravity-induced side load. Lubricate every
5,000km of cumulative stroke travel.
| Property | Property Value |
|---|---|
| sku | ATE12X5B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
