Airtac ATE Single Acting Guided Compact Cylinder ATE12X5SB
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE12X5SB Single-Acting Compact Cylinder Specifications
- Model: ATE12X5SB (Basic Type)
- Action type: Single-acting (spring return)
- Bore size: Φ12mm
- Stroke: 5mm (Standard stroke range: 5-100mm)
- Operating pressure: 0.05-0.9 MPa
- Port size: M5x0.8 (DIN3852-B metric thread)
- Cushioning: Elastic rubber buffer
- Mounting types: Foot-mounted (standard), front flange options available
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 0.28kg (without accessories)
- Dimensions:
- Body length: 40mm
- Overall length (stroke 5mm): 45mm
- Width (mounting foot span): 25mm
- Height (including rod): 56mm
Ultra-compact cylinder with 12mm bore designed for space-constrained automation systems. Features low-friction construction for precise short-stroke movements (≤5mm) and corrosion-resistant coating. Includes built-in auto-adjust cushioning to minimize end-impact noise. Requires 5μm filtered air with ISO VG32 turbine oil lubrication (optional oil-free operation).
- PCB board clamping mechanisms in electronics assembly
- Precision valve actuation in analytical instruments
- Micro-feeding systems for pharmaceutical blister packaging
- Wafer handling robotics in semiconductor manufacturing
Installation note:
Maintain 0.5-0.8 MPa optimal pressure for spring longevity. Lubricate every 3 months under continuous operation.
Avoid lateral loads exceeding 1.5N·m on piston rod.
| Property | Property Value |
|---|---|
| sku | ATE12X5SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
