Airtac B06-TN Battery-Specific Cylinder B06-TN16X150S
AirTAC B06-TN16X150S Battery-Optimized Cylinder Specifications
- Model: B06-TN16X150S
- Type: Compact double-acting pneumatic cylinder (battery system variant)
- Bore size: 16mm
- Stroke: 150mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable elastic buffer + shock absorber
- Piston rod material: Hard chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal type: HNBR seals (high-temp nitrile)
- Temperature range: -20℃ to 100℃ (dry air required above 70℃)
- Weight: 420g ±3% (excluding accessories)
- Dimensions:
- Extended length: 223mm
- Retracted length: 73mm
- Body diameter: Φ32mm
- Mounting base: 26mm × 20mm
- Port thread: M5×0.8 (dual ports)
- Lubrication: Pre-lubricated (maintenance-free for 2,000km operation)
- ISO standard: 6432 compliant
Ultra-lightweight cylinder engineered for battery-powered automation systems, featuring 35% reduced air consumption compared to standard models. The TN series incorporates a low-friction design with self-compensating seals, enabling stable operation at pressures as low as 0.05MPa. Integrated shock absorption minimizes vibration in high-cycle applications.
- Portable medical device actuators
- AGV (Automated Guided Vehicle) clamping systems
- Solar panel cleaning robot mechanisms
- Lithium battery assembly line positioning
- Drone-based inspection equipment
Installation guidelines:
Optimal performance achieved when mounted horizontally.
Use copper-free lubricants if external lubrication required.
Maximum side load: 15N (use guide mechanism for heavier loads).
