Airtac B06-TN Battery-Specific Cylinder B06-TN25X170S
AirTAC B06-TN25X170S Battery-Optimized Cylinder Specifications
- Model: B06-TN25X170S
- Type: Double-acting battery-driven cylinder
- Bore size: Ø25mm (precisely 25.4mm)
- Stroke: 170mm ±0.5mm tolerance
- Material: Anodized aluminum barrel, chrome-plated piston rod
- Seal type: NBR seals with dust-resistant wiper
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -20℃ to +80℃
- Buffer type: Adjustable air cushion (both ends)
- Mounting: ISO 6432 standard flange (MF1 pattern)
- Port size: M5x0.8 pneumatic ports
- Weight: 1.85kg ±3%
- Dimensions: 250mm(L) × 40mm(W) × 60mm(H)
- Rod thread: M10x1.25 female
- Position detection: Optional magnetic reed sensor slot
Specialized low-friction cylinder engineered for battery-powered pneumatic systems, featuring 35% reduced air consumption compared to standard models. The anti-corrosion design integrates copper-free components for cleanroom compatibility. Includes integrated mounting grooves for sensor brackets and an optimized flow path design achieving ≤0.15MPa minimum operating pressure.
- Lithium battery cell stacking machines
- Portable medical device actuators
- Solar-powered automated guided vehicles (AGVs)
- Battery pack assembly line positioning
- Robotic welding fixtures in EV production
Usage guidelines:
Requires ISO 8573-1:2010 Class 3-4-3 compressed air. Lubricate with ISO VG32 hydraulic oil if manual lubrication is used.
For battery systems, maintain 12V DC power supply with ≤5% voltage fluctuation. Avoid continuous duty cycles exceeding 70% at max pressure.
