Airtac B06-TN Battery-Specific Cylinder B06-TN32X80S
AirTAC B06-TN32X80S Battery-Optimized Cylinder Specifications
- Model: B06-TN32X80S
- Type: Compact battery-driven double-acting cylinder
- Bore size: 32mm
- Stroke: 80mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -10℃ to 60℃
- Cushioning: Adjustable air cushion (both ends)
- Piston speed: 50–800 mm/s
- Material: Aluminum alloy cylinder tube, SUS304 piston rod
- Seal material: NBR (Nitrile) with wear-resistant ring
- Mounting: Standard foot/base mount (MF1) or front flange (optional)
- Weight: 1.8kg (without accessories)
- Dimensions: 250mm(L) × 40mm(W) × 40mm(H) (fully retracted)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (maintenance-free for 2000km operation)
Ultra-low friction cylinder engineered for battery-powered automation systems, featuring 30% reduced air consumption compared to standard models. The anodized barrel and chrome-plated piston rod ensure corrosion resistance in humid environments. Integrated magnetic piston enables position feedback when used with sensors (not included).
- Mobile AGV (Automated Guided Vehicle) clamping systems
- Portable medical equipment actuators
- Solar-powered agricultural automation
- Battery-operated packaging machinery
- Laboratory automation with limited power supply
Installation guidelines:
Use copper-free lubricant (ISO VG32 recommended) if manual relubrication required.
Maintain 0.3mm minimum clearance between piston rod and guide mechanisms.
For vertical mounting, install exhaust mist lubricator upstream.
| Property | Property Value |
|---|---|
| sku | B06-TN32X80S |
