Airtac B06-TR Battery-Specific Cylinder B06-TR10X10S
AirTAC B06-TR10X10S Battery-Optimized Miniature Cylinder Specifications
- Model: B06-TR10X10S (TR=Thin Rod Series)
- Type: Single-acting spring return (battery-friendly design)
- Bore size: 10mm
- Stroke: 10mm
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -10℃ to 60℃ (extended range for battery environments)
- Buffer type: Fixed cushioning
- Mounting style: Basic female thread (M5x0.8 mounting holes)
- Port size: M3x0.5 (dual ports for compact routing)
- Rod material: Stainless steel SUS304
- Tube material: Aluminum alloy hard anodized
- Battery compatibility: 3-6V DC systems
- IP rating: IP54 (dust/water resistant)
- Max speed: 500 mm/s
- Repeat accuracy: ±0.1mm
- Lubrication: Pre-lubricated (maintenance-free for 2,000km)
- Weight: 0.25kg (including mounting hardware)
- Dimensions: 56mm(L) × 20mm(W) × 20mm(H) (compact cube design)
Ultra-compact pneumatic cylinder engineered for battery-powered automation systems, featuring 35% reduced air consumption compared to standard models. The copper-free rod design prevents electrolytic corrosion in humid environments. Integrated shock-absorbing pads minimize vibration transfer to sensitive electronics.
- Portable medical diagnostic equipment
- Battery-driven laboratory automation arms
- Mobile robot gripper mechanisms
- Solar-powered agricultural dosing systems
- Compact packaging machines with lithium battery packs
Installation protocol:
Use M5 titanium alloy screws to prevent galvanic corrosion. Maintain 15mm
clearance around cylinder body for heat dissipation. Requires dry air
(pressure dew point -20℃) to prevent internal icing in low-temp battery environments.
| Property | Property Value |
|---|---|
| sku | B06-TR10X10S |
