Airtac B06-TR Battery-Specific Cylinder B06-TR10X20S
AirTAC B06-TR10X20S Battery-Optimized Cylinder Specifications
- Model: B06-TR10X20S
- Type: Compact ISO cylinder with integrated battery control circuit
- Bore size: 10mm (0.39")
- Stroke: 20mm (0.79")
- Operating pressure: 0.05–0.7 MPa (7–101 PSI)
- Voltage compatibility: DC12V ±10% (with polarity protection)
- Current draw: ≤0.25A @ full load
- Material: Aluminum alloy barrel, CR-MO piston rod
- Seal type: Double-lip NBR seals with wear indicator
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 0.26kg (0.57 lbs)
- Dimensions: 85mm(L) × 32mm(W) × 32mm(H)
- Mounting: 2x M4 threaded holes (front flange pattern)
- Cushioning: Adjustable pneumatic buffer + rubber end stops
- IP rating: IP54 (dust protected, splash resistant)
- Cycle life: ≥1,000,000 cycles @ 0.5MPa
Ultra-compact pneumatic cylinder engineered for battery-powered automation systems, featuring an integrated low-power control circuit that reduces energy consumption by 40% compared to standard models. The optimized flow path design achieves 0.05MPa minimum operating pressure, making it ideal for portable devices. Includes auto-sleep mode after 60s of inactivity.
- Mobile laboratory analyzers
- AGV (Automated Guided Vehicle) clamping systems
- Portable medical suction devices
- Solar-powered agricultural actuators
- Robotic grippers in cleanroom environments
Installation notes:
Requires 5-10μm filtration. For vertical mounting, use the anti-drop lock nut (optional accessory B06-TR-AD).
Lubricate every 50km of cumulative stroke motion using ISO VG32 hydraulic oil.
Critical parameters:
- Max lateral load: 15N
- Do NOT use with pressure intensifiers
- Storage temperature must not exceed 50℃ when battery is connected
| Property | Property Value |
|---|---|
| sku | B06-TR10X20S |
