Airtac B06-TR Battery-Specific Cylinder B06-TR10X60S
AirTAC B06-TR10X60S Battery-Powered Cylinder Specifications
- Model: B06-TR10X60S
- Type: Compact battery-driven linear actuator (Double-acting)
- Bore size: Φ10mm (0.39")
- Stroke: 60mm (2.36")
- Operating pressure: 0.05–0.7 MPa (7–101 PSI)
- Battery voltage: DC3.7V (Lithium-ion integrated)
- Max thrust: 18N (forward), 14N (return) @0.5MPa
- Operating temperature: -10℃ to 60℃ (14℉ to 140℉)
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Weight: 480g (1.06 lbs) including battery
- Dimensions: 120mm(L) × 28mm(W) × 28mm(H)
- Position detection: Built-in magnetic sensor (PNP output)
- Battery life: 50,000 cycles @1Hz operation
- Protection rating: IP54 (Dust protected & water splashed)
Self-contained pneumatic actuator eliminating external air supply requirements. Features integrated energy recovery system that recharges the battery during deceleration phases. Optimized for silent operation (<35dB) with TÜV-certified low EMI emission. Includes auto-lock mechanism preventing unintended movement during power loss.
- Portable medical diagnostic equipment
- Mobile robotic grippers in cleanrooms
- Solar-powered agricultural actuators
- IoT-enabled smart furniture mechanisms
- Battery-operated inspection devices
Installation protocol:
Requires 2-point mechanical alignment during mounting. Battery compartment
must face downward in vertical installations. Perform initial 10 full-stroke
cycles without load for system calibration.
| Property | Property Value |
|---|---|
| sku | B06-TR10X60S |
