Airtac B06-TR Battery-Specific Cylinder B06-TR10X75S
AirTAC B06-TR10X75S Battery-Optimized Miniature Cylinder
- Full model: B06-TR10X75S
- Series: B06-TR (Battery Drive Series)
- Bore size: 10mm
- Stroke: 75mm ±0.5mm
- Operating pressure: 0.1-0.7 MPa
- Battery voltage: 3-6V DC (Lithium battery compatible)
- Current consumption: ≤80mA @ 3V
- Cushioning: Adjustable air cushion (dual-side)
- Piston speed: 50-700mm/s
- Operating temperature: -20℃ to 80℃
- Mounting type: Standard front flange (MF1) with rear pivot
- Port size: M5x0.8 pneumatic ports
- Material:
- Barrel: Hard anodized aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR/PU hybrid for low friction
- Weight: 520g ±10g (with mounting brackets)
- Dimensions:
- Length: 139mm (fully retracted)
- Width: 34mm (flange mounting surface)
- Height: 42mm (including rod end)
- IP rating: IP54 (dust protected & splash resistant)
Ultra-efficient pneumatic actuator designed for battery-powered automation systems. Features a low-friction dual-seal design reducing required operating pressure by 30% compared to standard cylinders. Integrated power-saving mode activates after 60s of inactivity. The corrosion-resistant construction withstands humid environments while maintaining 500km minimum service life at rated load.
- Portable medical diagnostic equipment
- Automated guided vehicle (AGV) clamping systems
- Solar-powered agricultural actuators
- Mobile laboratory automation arms
- Battery-operated packaging machines
Installation tips:
- Use M3x8 stainless screws for flange mounting (max torque 1.2N·m)
- Maintain ≥5mm clearance around cylinder body for heat dissipation
- Apply silicone-free lubricant (ISO VG32) every 50,000 cycles
| Property | Property Value |
|---|---|
| sku | B06-TR10X75S |
