Airtac B06-TR Battery-Specific Cylinder B06-TR16X20S
AirTAC B06-TR16X20S Battery-Optimized Miniature Cylinder
- Model Series: B06-TR (Battery-Driven Compact Series)
- Bore Size: 16mm (Precision Honed Tube)
- Stroke: 20mm (±1mm Tolerance)
- Action Type: Double Acting
- Operating Pressure: 0.1-0.9 MPa
- Cushioning: Adjustable Air Cushion (Both Ends)
- Body Material: Hard Anodized Aluminum Alloy
- Seal Material: High-Grade NBR (Oil/Fatigue Resistant)
- Mounting Options: Front Flange (Standard), Foot Mount (Optional)
- Weight: 0.42kg (Without Accessories)
- Dimensions: 80mm(L) × 45mm(W) × 40mm(H)
- Rod Thread: M6×1.0 External Thread
- Temperature Range: -10℃ to 80℃ (Non-Freezing Environment)
- Lubrication: Pre-Lubricated (Maintenance-Free Design)
- Repeat Accuracy: ±0.2mm
Ultra-compact pneumatic cylinder specifically engineered for battery-powered automation systems. Features 35% reduced air consumption compared to standard cylinders through optimized flow channels. Integrated shock-absorbing mechanism prevents overstroke in low-pressure environments (2-6V DC typical). Sealed against particulate ingress with IP54-rated wiper seals.
- Portable medical analyzers (blood test devices, PCR machines)
- Lithium battery assembly line actuators
- Solar-powered agricultural dosing systems
- Robotic grippers in cleanroom environments
- Automated vending machine mechanisms
Installation Protocol:
Requires 1.5x bore size clearance (24mm min.) for full stroke extension.
Use copper-free anti-seize compound on piston rod threads.
Maximum side load capacity: 12N at mid-stroke.
