Airtac B06-TR Battery-Specific Cylinder B06-TR16X30S
AirTAC B06-TR16X30S Battery-Optimized Cylinder Specifications
- Model: B06-TR16X30S
- Type: Compact double-acting cylinder (battery-driven)
- Bore size: 16mm
- Stroke: 30mm (±1mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer (both ends)
- Port thread: M5×0.8 (standard dual ports)
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 80℃
- Rod material: Stainless steel SUS304
- Body material: Anodized aluminum alloy
- Weight: 0.35kg (without mounting accessories)
- Dimensions: 110mm(L) × 30mm(W) × 30mm(H) (fully retracted)
- Protection rating: IP40 (standard), IP67 optional
- Lubrication: Pre-lubed (Grease-free operation compatible)
Ultra-low friction cylinder engineered for battery-powered automation systems, featuring 40% reduced air consumption compared to standard models. Integrated energy-saving design maintains consistent thrust while minimizing voltage drop risks in mobile applications. Includes anti-rotation guide slots for precise linear motion.
- Portable medical diagnostic equipment
- AGV (Automated Guided Vehicle) lifting mechanisms
- Solar-powered agricultural actuators
- Robotic grippers in cleanroom environments
- Battery-operated packaging machines
Installation guidelines:
Optimal performance achieved in horizontal orientation. Use shock-absorbing brackets
in high-vibration environments. For battery systems, maintain 12-24VDC power supply
with minimum 2A surge capacity. Allow 15mm clearance around cylinder body for heat
dissipation during continuous cycling.
| Property | Property Value |
|---|---|
| sku | B06-TR16X30S |
