Airtac B06-TR Battery-Specific Cylinder B06-TR16X70S
AirTAC B06-TR16X70S Battery-Optimized Cylinder Specifications
- Model: B06-TR16X70S
- Type: Single-rod double-acting pneumatic cylinder (battery system optimized)
- Bore size: 16mm (±0.1mm precision honing)
- Stroke: 70mm (adjustable cushioning)
- Operating pressure: 0.05–0.7 MPa
- Cushioning type: Air cushion adjustable via needle valves
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber) with low-friction design
- Operating temperature: -10℃ to 60℃ (humidity <90% RH)
- Port size: M5x0.8 (dual ports for forward/return strokes)
- Mounting: ISO 15552 front flange (alternative foot mounting available)
- Position detection: Built-in magnet for magnetic sensors (12-24VDC compatible)
- Protection rating: IP54 (dust/water resistant)
- Weight: 0.52kg (without accessories)
- Dimensions: 150mm(L) × 25mm(W) × 25mm(H) (stroke extended)
- Max theoretical force: 14.2N @0.5MPa (extend), 12.8N @0.5MPa (retract)
Ultra-low friction cylinder engineered for battery-powered automation systems, featuring 30% reduced air consumption compared to standard models. The chrome-silicon spring design ensures smooth operation even at minimal pressure (0.05MPa). Integrated oil-less construction eliminates lubrication requirements.
- Mobile solar panel positioning systems
- Portable medical ventilator mechanisms
- AGV (Automated Guided Vehicle) clamping units
- Battery-operated packaging machines
- IoT-enabled agricultural actuators
Installation protocol:
Maintain 0.05-0.15mm clearance between rod end and load during alignment.
Use M3 mounting screws with 0.6-0.8Nm torque. For battery systems, pair with
APE-08A series low-power valves (consumption <1.2W).
| Property | Property Value |
|---|---|
| sku | B06-TR16X70S |
