Airtac B06-TR Battery-Specific Cylinder B06-TR16X80S
AirTAC B06-TR16X80S Battery-Optimized Pneumatic Cylinder Specifications
- Model: B06-TR16X80S
- Type: Compact battery-driven double-acting cylinder
- Bore size: 16mm (0.63")
- Stroke: 80mm (3.15")
- Operating pressure: 0.05–0.7 MPa (7–101.5 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Rod material: Stainless steel SUS304
- Tube material: Anodized aluminum alloy
- Seal type: High-efficiency NBR seals
- Protection rating: IP67 (dust/water resistant)
- Mounting style: Front flange with through-hole (M6x1.0)
- Sensor compatible: Supports magnetic reed switch (M9 connector)
- Weight: 480g (1.06 lbs)
- Dimensions:
- Body length: 135mm (5.31")
- Extended length: 215mm (8.46")
- Width: 32mm (1.26")
- Height: 32mm (1.26")
Ultra-low friction cylinder engineered for battery-powered systems, featuring 30% reduced air consumption compared to standard models. The self-lubricating design eliminates need for external grease, with gold-anodized coating resisting chemical corrosion. Integrated mounting slots allow 360° position adjustment.
- Mobile medical carts (IV pumps, patient lifts)
- AGV (Automated Guided Vehicle) clamping systems
- Portable laboratory automation equipment
- Solar-powered agricultural actuators
- Battery-operated packaging machines
Installation tip:
For optimal battery life, maintain 0.3-0.5 MPa working pressure.
Use clean dry air with 5μm filtration. Avoid side-load forces exceeding 15N.
- Built-in air-saving circuit reduces battery drain
- Non-rotating piston rod with alignment grooves
- Shock-absorbing end caps with adjustable cushioning
- Corrosion-resistant for outdoor/medical environments
| Property | Property Value |
|---|---|
| sku | B06-TR16X80S |
