Airtac B06-TR Battery-Specific Cylinder B06-TR20X20S
AirTAC B06-TR20X20S Battery-Optimized Cylinder Specifications
- Model: B06-TR20X20S
- Type: Single-acting spring return cylinder (battery-specific design)
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -10℃ to 60℃
- Cushioning: Fixed rubber buffer
- Mounting style: Basic type (with optional foot/tie-rod mounts)
- Port size: M5x0.8
- Seal material: Low-friction NBR with wear-resistant guide rings
- Battery compatibility: Optimized for 12-24V DC systems
- Weight: 280g ±5g (excluding accessories)
- Dimensions:
- Extended length: 104mm
- Retracted length: 84mm
- Body diameter: 32mm
- Rod thread: M6x1.0
Compact pneumatic cylinder engineered for battery-powered automation systems, featuring reduced friction design (≤0.15 dynamic friction coefficient) for energy efficiency. The robust anodized aluminum construction ensures 500km+ service life under standard conditions. Includes integrated magnetic piston for position sensing compatibility.
- Mobile robotic arms in field operations
- Portable medical equipment actuators
- Solar-powered agricultural automation
- Battery-driven packaging/clamping systems
- IoT-enabled low-power pneumatic devices
Operation tip:
Maintain horizontal installation where possible to optimize lubrication distribution.
Use with filtered dry air (ISO 8573-1:2010 Class 2.4.2) and cycle rates below 80% duty
cycle for battery longevity. Avoid rapid pressure spikes above 0.8MPa.
| Property | Property Value |
|---|---|
| sku | B06-TR20X20S |
