Airtac B06-TR Battery-Specific Cylinder B06-TR25X20S
AirTAC B06-TR25X20S Battery-Powered Cylinder Specifications
- Model: B06-TR25X20S (Battery Series)
- Cylinder type: Single-acting spring return
- Bore size: Ø25mm (±0.1mm tolerance)
- Stroke: 20mm (adjustable with stroke limiter)
- Operating pressure: 0.05-0.7 MPa
- Battery voltage: 6V DC (built-in lithium pack)
- Current draw: 120mA @ max load
- Piston speed: 50-800mm/s
- Buffer type: Elastic rubber + energy-absorbing ring
- Mounting style: SW25 base with M6×1.0 mounting holes
- Port size: M5×0.8 pneumatic thread
- Temperature range: -10℃ to 60℃ (non-condensing)
- Body material: Anodized aluminum alloy (A6063)
- Rod material: Chrome-plated steel (STS420J2)
- Seal material: HNBR with low-friction coating
- Weight: 0.82kg (including battery)
- Dimensions: 130mm(L) × 45mm(W) × 60mm(H)
- Protection rating: IP54 (dust/water resistant)
Compact self-contained pneumatic actuator designed for battery-operated automation systems. Features integrated power management with auto-sleep mode (activates after 30min idle). The low-friction design enables operation at 30% lower pressure than standard cylinders. Includes magnetic piston for position sensing compatibility.
- Portable medical compression devices
- AGV (Automated Guided Vehicle) clamping systems
- Solar-powered agricultural actuators
- Battery-operated inspection equipment
- Mobile robotic gripper mechanisms
- Wireless-controlled exhibition displays
Installation notes:1. Maintain horizontal orientation for optimal lubrication distribution
2. Charge battery monthly when stored long-term
3. Use M5×0.8 to NPT adaptor for US standard pneumatic lines
4. Replace wear ring after 500,000 cycles in high-load applications
