Airtac B06-TR Battery-Specific Cylinder B06-TR25X30S
AirTAC B06-TR25X30S Battery-Optimized Cylinder Specifications
- Model Series: B06-TR (TR series for battery systems)
- Bore Size: Ø25mm precision honed cylinder
- Stroke: 30mm (±0.5mm tolerance)
- Operating Pressure: 0.05-0.9 MPa (ultra-low start pressure 0.03MPa)
- Battery Compatibility: 12-24V DC systems
- Air Consumption: 3.2cm³/stroke @ 0.5MPa
- Piston Speed: 50-800mm/s (battery-optimized flow control)
- Mounting: Standard ISO 15552 front flange with M6x1.0 mounting holes
- Rod End: M6x1.0 internal thread (stainless steel 303)
- Seal Material: HNBR rubber (-20℃ to 120℃)
- Cushioning: Adjustable pneumatic cushion + shock absorber pad
- Position Detection: Built-in magnet for sensor mounting (SMCR-8 compatible)
- Weight: 480g ±2% (aluminum body construction)
- Dimensions: 155mm(L) × 40mm(W) × 40mm(H) (compact profile)
- Cycle Life: 5,000km travel distance (IP67 sealed)
Specialized low-power pneumatic cylinder engineered for battery-operated automation systems. Features ultra-smooth Teflon®-impregnated seals and reduced friction design, achieving 35% lower air consumption than standard models. The anti-corrosion hard anodized surface withstands industrial washdown environments.
- Mobile battery-powered AGV transfer arms
- Portable medical oxygen concentrator mechanisms
- Solar-powered agricultural sorting gates
- Lithium battery production line handling
- Outdoor IoT-enabled monitoring equipment actuators
Installation note:
For optimal battery life, pair with 0.5μm precision filter and maintain 0.3-0.6MPa working pressure.
Lubrication-free design - do not add grease to sliding parts.
| Property | Property Value |
|---|---|
| sku | B06-TR25X30S |
