Airtac CM3HD Double Acting Selector Mechanical Valve CM3HD06-P1
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multiple actuator configurations for diverse application requirements.
3. Poppet valve structure ensures superior sealing performance and smooth directional switching without lubrication requirements.
4. Supports versatile mounting orientations for enhanced installation flexibility.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuator heads for extended service life and operational reliability.
6. CM3PMS and CM3PMX series are equipped with protective metal shrouds to prevent accidental actuation and ensure button integrity.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3HD
AirTAC CM3HD Double-Action Selector Mechanical Valve CM3HD06-P1 Technical Details
- Model: CM3HD06-P1
- Type: 4-way/3-position double-action selector valve (manual override)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Max flow rate: 450 NL/min (ANR)
- Actuation force: 3.5N ±0.5N at lever tip
- Body material: Nickel-plated brass
- Seal material: Heat-resistant HNBR (-20℃ to 120℃)
- Weight: 235g ±5g
- Dimensions: 58mm(L) × 42mm(W) × 34mm(H)
- Port thread depth: 9.5mm (minimum engagement)
- Max cycling frequency: 1,200 cycles/hour
- Vibration resistance: 10–55Hz with 1.5mm amplitude
- Shock resistance: 100m/s² (3 axes)
- Protection rating: IP67 (dust/water ingress)
Robust mechanical valve with dual-position detent mechanism for precise directional control in harsh environments. Features anti-corrosion plating and ergonomic lever design with tactile feedback. Requires 5–7 bar lubricated air (ISO VG32 recommended). Includes built-in manual override for emergency operation.
- Pneumatic press clamping systems
- Textile machinery cylinder control
- Food processing actuator sequencing
- Construction equipment brake controls
- Semiconductor handling robots
Installation guidelines:
Mount in vibration-dampened panels using M4 screws (max torque 1.2N·m).
Maintain 15° lever swing clearance. Use Loctite 243 on exhaust port threads.
Perform monthly lubrication checks in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | CM3HD06-P1 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
