Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP06-P2
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PP06-P2
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Product Description:**
1. The CM3B, CM3L, CM3V, and CM3R series require externally applied force for valve actuation, making them ideal for position detection or as limit switches.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
Installation note:
Ensure minimum 15mm front panel thickness for secure mounting.
Apply thread sealant only on port threads (not mounting threads).
For vertical mounting, orient exhaust port downward to prevent debris ingress.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Plunger Button Mechanical Valve CM3PP06-P2 Specifications
- Model: CM3PP06-P2
- Type: 3/2-way normally closed (manual mechanical operation)
- Port size: PT1/8 (G1/8 equivalent)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) with optional FKM seals (-20℃ to 150℃)
- Temperature range: -20℃ to 80℃ (standard seals)
- Actuation force: 3.5-4.5N (manual push operation)
- Mounting style: Panel-mount with M5 mounting threads
- Weight: 185g ±5g
- Dimensions: 52mm(L) × 34mm(W) × 63mm(H)
- Port thread depth: 9mm (full thread engagement)
- Contact rating: 1A 24VDC (gold-plated contacts)
- Mechanical life: ≥500,000 cycles
- IP rating: IP67 (dust/water resistant)
Manual override valve with tactile feedback, featuring a 12mm diameter stainless steel plunger with anti-slip knurling. The dual-color (red/black) button provides visual status indication. Includes built-in silencer for exhaust air noise reduction (62dB(A) max). Compatible with ISO 15407-1 standards for pneumatic valves.
Typical Applications:
- Emergency stop systems in automated machinery
- Manual process override in semiconductor manufacturing
- Test bench pneumatic circuit control
- Maintenance bypass in packaging lines
- Educational pneumatic training boards
Installation note:
Ensure minimum 15mm front panel thickness for secure mounting.
Apply thread sealant only on port threads (not mounting threads).
For vertical mounting, orient exhaust port downward to prevent debris ingress.
| Property | Property Value |
|---|---|
| sku | CM3PP06-P2 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
