Airtac DPS Electronic Digital Display Pressure Sensor DPSN1B-10050
$56.98
Regular price
$64.48
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
DPSN1B-10050
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Avoid dropping, striking, or subjecting to excessive impact to prevent internal damage and malfunction.
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
Installation guidelines:
Mount with 17mm wrench flats using 30-35Nm torque. Use pulsation damper
when measuring reciprocating pump pressures. Maintain 50mm clearance
behind display for visibility. Requires 60μm inline filter for abrasive media.
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPSN1B-10050 Electronic Digital Pressure Sensor Specifications
- Model: DPSN1B-10050
- Pressure range: 0.1-50.0 MPa (1450-7250 PSI)
- Accuracy: ±0.5% F.S. (±1.0% optional)
- Power supply: 12-24VDC ±10% (ripple ≤100mV)
- Output signal: 4-20mA (2-wire) / 0-10V (3-wire)
- Display: 4-digit LED with 0.36" character height
- Sampling rate: 10 times/sec
- Response time: ≤2ms
- Protection rating: IP67 (NEMA 4X equivalent)
- Process connection: G1/4" male thread (NPT optional)
- Seal material: FKM fluorocarbon rubber
- Media temperature: -20℃ to 85℃ (-4°F to 185°F)
- Ambient temperature: -10℃ to 60℃ (14°F to 140°F)
- Storage temperature: -30℃ to 70℃ (-22°F to 158°F)
- Electrical connection: M12 4-pin connector (IP67 rated)
- Housing material: 304 stainless steel
- Weight: 280g ±5g (excluding cable)
- Dimensions: 78mm(L) × 42mm(W) × 38mm(H)
High-precision industrial pressure sensor with dynamic compensation algorithm for stable readings under vibration. Features auto-power-off after 30 minutes idle and 360° rotatable display. Certified for burst pressure up to 150MPa with over-range protection circuitry.
Typical Applications:
- Hydraulic press pressure monitoring
- CNC machine tool lubrication systems
- Plastic injection molding pressure feedback
- Test bench calibration systems
- Industrial waterjet cutting equipment
- Pneumatic energy storage monitoring
Installation guidelines:
Mount with 17mm wrench flats using 30-35Nm torque. Use pulsation damper
when measuring reciprocating pump pressures. Maintain 50mm clearance
behind display for visibility. Requires 60μm inline filter for abrasive media.
| Property | Property Value |
|---|---|
| sku | DPSN1B-10050 |
