Airtac ESV-M Base ESV201M
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Series Base Unit ESV201M Technical Specifications
- Model: ESV201M (ESV-M series modular base)
- Compatible Valves: Designed for M5 thread solenoid valves (ESV-M series)
- Port configuration: 5-port (P, A, B, R1, R2)
- Port size: M5×0.8 thread
- Max operating pressure: 1.0 MPa
- Pressure range: 0.15–1.0 MPa
- Flow characteristics: Cv value 0.15
- Mounting pattern: ISO G1/8 (optional G1/4 adapter available)
- Weight: 220g ±5%
- Dimensions: 40mm(L) × 30mm(W) × 25mm(H)
- Body material: Reinforced PBT resin (30% glass fiber)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -20℃ to 80℃ (no ice formation)
- Vibration resistance: 10–55Hz with 1.5mm amplitude
- Shock resistance: 100m/s² (approx. 10G) in XYZ axes
- Protection rating: IP40 (terminal cover included)
Modular manifold base enabling multi-valve stacking with centralized exhaust. Features integrated silencer pockets and color-coded port indicators (P-red, A-blue, B-orange). Optimized flow paths reduce pressure drop by 18% compared to previous generation. Includes built-in mounting slots for DIN rail (TH35-7.5) or direct panel mounting.
- Centralized control systems for packaging machinery
- Multi-station pneumatic control in automotive assembly lines
- Compact valve clusters for semiconductor handling robots
- Modular pneumatic teaching equipment
Installation protocol:
Apply 0.5–0.7Nm torque during valve mounting. Use spacer plates (ESV-SP1) when stacking >3 units.
Always connect exhaust ports downward to prevent debris ingress.
| Property | Property Value |
|---|---|
| sku | ESV201M |
| Port Size | PT1/4 |
