Airtac ESV-M Base ESV201MB
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base Unit ESV201MB Technical Specifications
- Model: ESV201MB (Compatible with ESV-M10/M20 series valves)
- Type: Modular manifold base for multiple valve assembly
- Port size: 1/8" NPT (G1/8 optional)
- Material: Reinforced nylon with fiberglass (UL94 V-0 rated)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Temperature range: -5℃ to 60℃ (23℉ to 140℉)
- Mounting: DIN rail (35mm) or direct panel mounting
- Weight: 195g ±5g (0.43 lbs)
- Dimensions: 62mm(L) × 34mm(W) × 28mm(H) (2.44" × 1.34" × 1.10")
- Port configuration: 1-inlet (P), 2-outlets (A/B), 1-exhaust (R)
- Seal material: HNBR (Hydrogenated Nitrile)
- Protection rating: IP54 (dust protected, water splashed)
- Certification: RoHS compliant, CE marked
Modular base unit enabling multi-valve stacking with centralized air distribution. Features integrated O-ring groove design for leak-free connections and staggered exhaust ports to prevent cross-contamination. The anodized aluminum end plates provide structural rigidity for up to 10-valve assemblies.
- Centralized control systems for automated assembly lines
- Multi-axis robotic gripper pneumatic circuits
- Textile machinery air distribution networks
- Semiconductor handling equipment clusters
- Modular packaging machine valve islands
Installation protocol:
Apply 3.5-4.5 N·m torque during manifold stacking. Use only compatible
ESV-M series valves. Perform air purge for 30 seconds before initial
activation to clear machining residues.
| Property | Property Value |
|---|---|
| sku | ESV201MB |
| Port Size | PT1/4 |
