AirTAC ESV200-BASE · ISO Valve Base

Airtac ESV-M Base ESV202M

Genuine AirTAC iso valve base, order code ESV202M from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotLeft ports · independent pilot
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT1/4
  • End-plate portsPT3/8
$25.55 $33.05Save 22%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV200-BASE part, ports and pilot and port thread on one page All ESV200-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV202M

The ESV202M is one station of an AirTAC ESV200 manifold. It carries an ESV2x0 solenoid or EAV2x0 air-piloted valve on the ISO 5599-1 mounting face and exposes PT1/4 working ports on the left side, the default port position for a manifold base. Each station has its own independent external pilot port, so externally piloted valves can be fed individually where actuation timing differs from station to station.

Manifold bases bolt together into a bank of any number of stations, and the bank is closed at both ends by an ESV203M end plate set, which raises the supply and exhaust connections one size to PT3/8 to feed the whole string. Like every ESV200 base, each station has a built-in exhaust throttle: adjust with a hex key, clockwise to reduce exhaust flow, and skip separate speed controllers.

Airtac ESV-M Base ESV202M Technical Specifications

Order codeESV202M
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotLeft ports · independent pilot
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT1/4
End-plate portsPT3/8
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Choose the ESV202M when piping exits sideways to the left and each piloted valve needs its own pilot feed. If your hoses must leave downward, order the ESV202MB bottom-port version instead; for right-side routing, the ESV202MR swaps the port position. If a single centralized pilot supply from the end plate suits your machine better than one port per station, move to the W (centralized external pilot) variant. Air to the ports should be filtered by a 40 um element.

Applications

view_module

Multistation bank with per-station piloting

A transfer line with several ESV2x0 valves bolts ESV202M stations side by side; the independent pilot port at every station lets each externally piloted valve be fed on its own schedule before the ESV203M end plate set closes the bank.

conveyor_belt

Conveyor stop-and-sort section

Stations along a conveyor drive diverters and stops from left-facing PT1/4 ports, keeping hoses clear of the product flow while the built-in exhaust throttle sets cushioning speed at each base.

inventory_2

Expandable spares position

A bank can start with one ESV202M and grow: extra bases bolt on for spare valve positions, and the ESV203M end plate set with PT3/8 supply and exhaust ports is resized or repositioned as the bank lengthens.

FAQ

What are the key figures of the ESV202M?

Manifold base (2M) for ESV2x0 and EAV2x0 valves on the ISO 5599-1 face. Working ports are PT1/4, positioned on the left (blank port code), with an independent external pilot port per station. End plate set ESV203M closes the manifold, its ports being PT3/8. Proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, built-in exhaust throttle, air filtered by a 40 um element. Exact dimensions: confirm from the datasheet.

How do independent and centralized pilot ports differ on this manifold?

The ESV202M gives every station its own independent external pilot port, so each externally piloted valve is piped and fed separately. If you prefer one pilot supply for the whole bank, taken from the end plate, order the W option (centralized external pilot port) instead; the pilot port only matters for externally piloted valves, not for internally piloted solenoid types.
