Genuine AirTAC iso valve base, order code ESV202MB from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
The ESV202MB is the bottom-port manifold station of the AirTAC ESV200 series: the B in the code moves the PT1/4 working ports from the side to the underside of the base, while the valve still mounts on the ISO 5599-1 face of an ESV2x0 solenoid or EAV2x0 air-piloted valve. Each station keeps an independent external pilot port, so piloted valves on the bank can be fed one by one.
Stations bolt together into a manifold of any length, closed by an ESV203M end plate set whose supply and exhaust ports are one size larger at PT3/8. Any bottom port left unused must be closed with a plug, as the catalog directs. Speed control comes built in: the exhaust throttle on each base is turned with a hex key, clockwise to reduce exhaust flow, replacing separate speed controllers on the valve ports.
| Order code | ESV202MB |
|---|---|
| Product | ISO Valve Base |
| Part | Manifold base (2M) |
| Ports and pilot | Bottom ports (B) · independent pilot |
| Port thread | PT |
| Parts | Single base (1M), Manifold base (2M), End plate set (3M) |
|---|---|
| Working ports | PT1/4 |
| End-plate ports | PT3/8 |
| Mounting face | ISO 5599-1 |
| Fluid | Air (filtered by 40 µm element) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Exhaust throttle | Built in |
Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.
Take the ESV202MB when manifold piping must drop below the bank. The ESV202M keeps the same independent pilot but routes ports to the left, and the ESV202MR routes them to the right; all three share PT thread. If the whole bank should share one pilot supply instead of per-station ports, choose the W centralized-pilot variant. Remember the 3M end plate set is ordered separately and its ports are PT3/8, one size above the PT1/4 working ports.
On a machine where the valve bank sits above moving components, ESV202MB stations send PT1/4 lines downward so hoses stay out of the moving envelope, while each station still has its own independent pilot port.
A compact bank of ESV2x0 valves bolts ESV202MB stations together for closely packed actuation points, with the ESV203M end plate feeding the string through its larger PT3/8 supply and exhaust ports.
On a forklift-served skid where impacts threaten side-facing fittings, bottom ports on the ESV202MB protect PT1/4 connections beneath the base, and unused bottom ports are simply closed with plugs.
Manifold base (2M) with bottom working ports (option B) in PT thread at the PT1/4 size, an independent external pilot port per station, and the ISO 5599-1 mounting face for ESV2x0 and EAV2x0 valves. Manifolds close with the ESV203M end plate set, whose ports are PT3/8. Proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, built-in exhaust throttle, air filtered by a 40 um element. Exact dimensions: confirm from the datasheet.
Every bottom port you do not use has to be closed with a plug, so count your valve ports before ordering. Also remember the end plate set (3M) is a separate line item and its supply and exhaust ports are PT3/8, one size larger than the PT1/4 working ports, so prepare a reducing connection between the bank supply and the station ports.
