AirTAC ESV200-BASE · ISO Valve Base

Airtac ESV-M Base ESV202MGB

Genuine AirTAC iso valve base, order code ESV202MGB from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotBottom ports (B) · independent pilot
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT1/4
  • End-plate portsPT3/8
$25.55 $33.05Save 22%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV200-BASE part, ports and pilot and port thread on one page All ESV200-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV202MGB

As part of the AirTAC ESV200 series, this 2M manifold base carries ESV2x0 solenoid valves or EAV2x0 air-piloted valves on an ISO 5599-1 mounting face and exposes the PT1/4 working ports underneath, delivered here in G (BSPP) thread, marked G. Proof pressure is 1.5 MPa (215 psi) and the fluid must be air filtered by a 40 um element.

Because the code leaves the pilot option blank, each station gets its own independent external pilot port, so an externally piloted valve is fed separately from its neighbours. Unused bottom ports are closed with plugs, and the built-in exhaust throttles are set with a hex key, clockwise to reduce exhaust flow, so no separate speed controller is needed.

Airtac ESV-M Base ESV202MGB Technical Specifications

Order codeESV202MGB
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotBottom ports (B) · independent pilot
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT1/4
End-plate portsPT3/8
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Choose this B-suffix base when the air lines must leave the manifold downward, for example into a machine bed or cable duct. Against ESV202MG, which on a manifold base gives left-side ports with the same independent pilot, it frees both side faces for access; against ESV202MGR the ports point down instead of right; and unlike ESV202MGW the pilot is independent rather than centralized from the end plate. Bolt together one 2M base per valve and add one ESV203M end plate set in G thread per manifold.

Applications

packaging

Packaging machine valve banks

Pick-and-place and clamp stations fed from below, where tube routing runs through the machine frame under the manifold instead of along its sides.

factory

Independently piloted stations

Multi-station panels built around externally piloted ESV2x0 valves where every station needs its own pilot connection rather than a shared supply.

settings

Compact control enclosures

ISO 5599-1 valves mounted above a mounting plate with all PT1/4 G-thread plumbing hidden underneath, keeping the enclosure interior clear.

FAQ

What are the key figures of the ESV202MGB?

It is the manifold base (2M) of the ESV200 series: PT1/4 working ports in G (BSPP) thread pointing downward, ISO 5599-1 mounting face, proof pressure 1.5 MPa (215 psi), temperature range -20 to +70 C, air filtered by a 40 um element, independent external pilot port, and built-in exhaust throttle.

How do I complete the manifold assembly?

Use one 2M base per valve, bolt the bases together, and close the row with one ESV203M end plate set in G thread, whose supply and exhaust ports are one size larger at PT3/8. Any bottom ports left unused are closed with plugs. Confirm remaining details from the datasheet.
