AirTAC ESV200-BASE · ISO Valve Base

Airtac ESV-M Base ESV202MGR

Genuine AirTAC iso valve base, order code ESV202MGR from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotRight ports (R) · independent pilot
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT1/4
  • End-plate portsPT3/8
$25.55 $33.05Save 22%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV200-BASE part, ports and pilot and port thread on one page All ESV200-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV202MGR

On this ESV200-series 2M base the working ports face the right side of the manifold, so ESV2x0 solenoid and EAV2x0 air-piloted valves still snap onto the ISO 5599-1 mounting face while the PT1/4 G (BSPP) connections line up along one edge for tidy tube routing. Working temperature spans -20 to +70 C and proof pressure is 1.5 MPa (215 psi).

The base bolts together with further 2M bases into any number of stations and is closed by an ESV203M end plate set, whose supply and exhaust ports are one size larger at PT3/8. With no W in the code, each station keeps its own independent external pilot port, and the built-in exhaust throttle is adjusted with a hex key, clockwise to reduce exhaust flow.

Airtac ESV-M Base ESV202MGR Technical Specifications

Order codeESV202MGR
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotRight ports (R) · independent pilot
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT1/4
End-plate portsPT3/8
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

If your piping runs along the opposite edge, order ESV202MG, which gives left-facing ports with the same independent pilot setup; ESV202MGB points the ports downward for under-manifold routing; and ESV202MGW trades the per-station pilot port for one centralized pilot supply fed from the end plate. This code is ordered with G for BSPP thread; leave the thread position blank to receive PT.

Applications

conveyor_belt

Conveyor diverters and stoppers

Right-side PT1/4 ports keep air lines routed along one edge of the manifold row driving diverters, stoppers and pushers on conveyor lines.

factory

Machine-side valve banks

Installations where the left side of the manifold must stay clear for valve removal, indicator access or cabling, with all air connections taken on the right.

widgets

Growing modular panels

Pneumatic control panels that expand station by station by bolting on additional 2M bases and finishing the row with a 3M end plate set.

FAQ

What are the key figures of the ESV202MGR?

Manifold base (2M) of the ESV200 series: PT1/4 working ports facing right in G (BSPP) thread, ISO 5599-1 mounting face, independent external pilot port, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, air filtered by a 40 um element, built-in exhaust throttle.

Can the exhaust flow be adjusted on this base?

Yes. The exhaust throttle is built into the base: turn the adjusting screw clockwise with a hex key to reduce exhaust flow. This means no separate speed controller is needed for the valve's exhaust side.
