AirTAC ESV200-BASE · ISO Valve Base

Airtac ESV-M Base ESV202MGWB

Genuine AirTAC iso valve base, order code ESV202MGWB from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotBottom ports (B) · centralized pilot (W)
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT1/4
  • End-plate portsPT3/8
$25.55 $33.05Save 22%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV200-BASE part, ports and pilot and port thread on one page All ESV200-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV202MGWB

This manifold base (2M in the AirTAC ordering code) carries ESV2x0 solenoid and EAV2x0 air-piloted valves on the ISO 5599-1 mounting face and delivers the PT1/4-size working ports cut as G (BSPP) thread. The B option points those ports out of the bottom of the base, so airlines drop vertically under the valve bank instead of leaving from the side.

The W option gives a centralized external pilot port: externally piloted valves are fed from one pilot line entering at the end plate rather than one port per station. Every base also carries a built-in exhaust throttle - turn the adjusting screw clockwise with a hex key to reduce exhaust flow - and unused bottom ports are closed with plugs. Bolt as many 2M bases as you have valves, then seal the bank with an ESV203M (3M) end plate set whose supply and exhaust ports step up to PT3/8.

Airtac ESV-M Base ESV202MGWB Technical Specifications

Order codeESV202MGWB
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotBottom ports (B) · centralized pilot (W)
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT1/4
End-plate portsPT3/8
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Choose ESV202MGWB over its G-thread sibling ESV202MGB when one shared pilot supply across the whole manifold is preferable to an independent pilot port on every station. Pick ESV202MGWR if piping must exit sideways to the right, or the PT-thread ESV202MB if your fittings are PT rather than BSPP. One 2M base per valve plus a single 3M end plate set completes the manifold.

Applications

packaging

Packaging machine valve island

Bottom-facing G ports let PT1/4 airlines drop below the frame, while the centralized W pilot shares a single feed across the whole ESV2x0 bank.

conveyor_belt

Conveyor divert stations

With hoses clear of the belt edge, the built-in exhaust throttle - turned clockwise with a hex key - damps each divert cylinder without extra speed fittings.

factory

Compact valve cabinets

Downward piping plus one centralized pilot line shortens cabinet plumbing; the bank is closed by a 3M end plate set with PT3/8 supply and exhaust.

FAQ

What are the key figures of the ESV202MGWB?

Working ports PT1/4 size in G (BSPP) thread on the bottom face; centralized external pilot (W) fed from the end plate; ISO 5599-1 mounting face; proof pressure 1.5 MPa (215 psi); air filtered by a 40 um element; temperature -20 to +70 C; exhaust throttle built in; end plate ports PT3/8.

How does the centralized W pilot work on this base?

Instead of an independent pilot port on every station, the W option feeds all externally piloted valves from one pilot line entering through the 3M end plate set. That saves a pilot tube per station on long manifolds; if you later need per-station pilots, order the same layout as ESV202MGB.
