AirTAC ESV200-BASE · ISO Valve Base

Airtac ESV-M Base ESV202MGWR

Genuine AirTAC iso valve base, order code ESV202MGWR from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotRight ports (R) · centralized pilot (W)
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT1/4
  • End-plate portsPT3/8
$25.55 $33.05Save 22%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV200-BASE part, ports and pilot and port thread on one page All ESV200-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV202MGWR

In the AirTAC ordering code this is the 2M manifold base with the R option: working ports leave the right-hand face, cut with G (BSPP) thread at PT1/4 size. It seats ESV2x0 solenoid and EAV2x0 air-piloted valves on the standardized ISO 5599-1 face, and the W option centralizes the external pilot so a single line from the end plate serves every station.

Bases bolt together into a bank of any number of stations, closed off by an ESV203M (3M) end plate set whose supply and exhaust ports are one size larger at PT3/8. Each base carries a built-in exhaust throttle: turn the adjusting screw clockwise with a hex key to reduce exhaust flow, so no separate speed controller is needed on the actuator lines.

Airtac ESV-M Base ESV202MGWR Technical Specifications

Order codeESV202MGWR
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotRight ports (R) · centralized pilot (W)
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT1/4
End-plate portsPT3/8
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Take ESV202MGWR rather than ESV202MGWB when hoses must leave sideways to the right instead of dropping below the bank, and rather than ESV202MGB when one centralized pilot line beats an independent pilot port per station. If your plant fittings are PT, the same right-port layout exists as the PT-thread ESV202MR.

Applications

widgets

Robot cell valve panel

Right-facing G ports line up with a side-mounted air distributor, and the centralized pilot keeps externally piloted EAV2x0 valves on one shared feed.

warehouse

Sorting gate control

A row of 2M bases drives diverter gates sideways off the bank, with the built-in exhaust throttle cushioning each gate cylinder without added fittings.

build

Machine retrofit with BSPP pipework

G (BSPP) thread matches existing European fittings on retrofitted equipment, and right-side ports suit manifolds mounted flush against a machine wall.

FAQ

What are the key figures of the ESV202MGWR?

Working ports PT1/4 size in G (BSPP) thread on the right face; centralized external pilot (W) fed from the end plate; ISO 5599-1 mounting face; proof pressure 1.5 MPa (215 psi); air filtered by a 40 um element; temperature -20 to +70 C; built-in exhaust throttle; end plate ports PT3/8.

Do I still need external speed controllers with this base?

For meter-out on the exhaust side, no: every base has a built-in exhaust throttle. Turn the adjusting screw clockwise with a hex key to reduce exhaust flow, or counter-clockwise to open it, sizing cylinder speed without a separate fitting.
