Airtac ESV-M Base ESV202MR
$25.55
Regular price
$33.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ESV202MR
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ESV-M Base Features:
1. Sleek appearance with compact structural design;
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
Installation protocol:
Torque mounting screws to 0.6-0.8 N·m in crisscross sequence.
Apply silicone-free lubricant on seals when assembling sub-bases.
Maximum 12-unit stack recommended for structural stability.
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base Unit ESV202MR Technical Specifications
- Model: ESV202MR (ESV-M series)
- Type: Modular valve manifold base
- Port size: G1/8 (Rc1/8 optional)
- Max operating pressure: 0.9 MPa
- Flow capacity: 750 L/min (ANR)
- Mounting pitch: 20 mm
- Material: Reinforced PA66 + glass fiber
- Seal type: Integrated NBR gasket
- Temperature range: -5℃ to 60℃ (with 20% humidity buffer)
- Weight: 280g ±5g
- Dimensions: 78mm(L) × 42mm(W) × 36mm(H)
- Compatibility: ESV-M series valves (1/4" bore size)
- Surface finish: Oil-resistant textured coating
- Certification: RoHS compliant
High-density modular base for multi-valve configurations, featuring integrated air passages and leak-proof design. The staggered port arrangement enables space-efficient manifold assemblies. Precision-molded with self-locking DIN rail clips and optional side-mount brackets.
Primary Applications:
- Centralized pneumatic control panels
- Automated assembly line manifolds
- Robotic end-effector valve clusters
- CNC machine tool pneumatic circuits
- Cleanroom-compatible equipment setups
Installation protocol:
Torque mounting screws to 0.6-0.8 N·m in crisscross sequence.
Apply silicone-free lubricant on seals when assembling sub-bases.
Maximum 12-unit stack recommended for structural stability.
| Property | Property Value |
|---|---|
| sku | ESV202MR |
| Port Size | PT1/4 |
