AirTAC ESV200-BASE · ISO Valve Base

Airtac ESV-M Base ESV202MW

Genuine AirTAC iso valve base, order code ESV202MW from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotLeft ports · centralized pilot (W)
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT1/4
  • End-plate portsPT3/8
$25.55 $33.05Save 22%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV200-BASE part, ports and pilot and port thread on one page All ESV200-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV202MW

AirTAC's ESV202MW manifold base (2M) from the ESV200 series carries ESV2x0 solenoid and EAV2x0 air-piloted valves on the ISO 5599-1 mounting face. One base holds one valve, and 2M bases bolt together into a run of any number of stations, closed off by an end plate set (3M) whose supply and exhaust ports are one size larger at PT3/8. On this code the PT1/4 working ports sit on the left side, and the W option centralizes the external pilot port: the whole manifold is fed from one point at the end plate instead of piping each station separately.

Every base includes a built-in exhaust throttle, so cylinder speeds can be tuned right at the valve bank - turn the adjusting screw with a hex key, clockwise to reduce exhaust flow - with no separate speed controller needed. Threads are PT as standard; a G-thread version carries G in its code.

Airtac ESV-M Base ESV202MW Technical Specifications

Order codeESV202MW
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotLeft ports · centralized pilot (W)
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT1/4
End-plate portsPT3/8
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Choose ESV202MW when the valves sit in a manifold row and the tubing leaves sideways to the left of each station. If the plumbing runs downward, order ESV202MWB (bottom ports); if it runs to the right, order ESV202MWR. A single valve on its own is better served by the 1M single base, and every 2M run needs one 3M end plate set to close it.

Applications

packaging

Multi-station packaging lines

Bolt a row of ESV202MW bases under ESV2x0 valves on a cartoner or case packer and route all PT1/4 left-side working ports in one direction along the machine frame.

tune

Centralized pilot plumbing

With the W option, one pilot line taken from the 3M end plate serves every externally piloted EAV2x0 valve in the run, so a six-station assembly press needs no per-valve pilot tubing.

conveyor_belt

Conveyor diverter valve banks

Drive diverter and stopper cylinders on conveyor systems where solenoid valves are banked together and the air lines exit left toward the machine edge.

FAQ

Which ports and threads does the ESV202MW have?

Working ports are PT1/4 on the left side of the base, and a 3M end plate set closes the manifold with PT3/8 supply and exhaust ports. The W option centralizes the external pilot at the end plate. Threads are PT as standard; G thread is marked G in the code.

What are the key figures of this base?

Mounting face ISO 5599-1; working ports PT1/4 (left); end-plate ports PT3/8; fluid air filtered by a 40 um element; proof pressure 1.5 MPa (215 psi); temperature -20 to +70 C; built-in exhaust throttle adjusted with a hex key.
