AirTAC ESV200-BASE · ISO Valve Base

Airtac ESV-M Base ESV202MWB

Genuine AirTAC iso valve base, order code ESV202MWB from the ESV200-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotBottom ports (B) · centralized pilot (W)
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT1/4
  • End-plate portsPT3/8
$25.55 $33.05Save 22%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV200-BASE part, ports and pilot and port thread on one page All ESV200-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV202MWB

In the AirTAC ESV200 series, the ESV202MWB manifold base (2M) carries ESV2x0 solenoid or EAV2x0 air-piloted valves on the ISO 5599-1 mounting face. The B option moves the PT1/4 working ports to the bottom of the base, keeping the side faces clear for tubing that drops straight down, and any unused bottom ports are closed with plugs. As on every 2M base, one base holds one valve and the bases bolt into runs of any length, sealed by a 3M end plate set with one-size-larger PT3/8 supply and exhaust ports.

The W centralized pilot port feeds all stations from the end plate rather than piping each base separately. An exhaust throttle is built into every base: turn the adjusting screw clockwise with a hex key to reduce exhaust flow, so downstream cylinders can be speed-controlled without a separate speed controller. Threads are PT as standard; G-thread versions carry G in the code.

Airtac ESV-M Base ESV202MWB Technical Specifications

Order codeESV202MWB
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotBottom ports (B) · centralized pilot (W)
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT1/4
End-plate portsPT3/8
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Pick ESV202MWB over ESV202MW (left ports) or ESV202MWR (right ports) when the manifold is frame mounted and hoses should leave downward. The bottom position applies per base, so unused bottom ports must be plugged. A standalone valve does not need this 2M base - use the 1M single base instead - and every 2M run must be finished with one 3M end plate set.

Applications

vertical_align_bottom

Down-drop valve banks

Mount the bank above the machine bed on a press or weld fixture and let the PT1/4 bottom ports feed cylinders by the shortest vertical run.

factory

Clean machine-front layouts

Keep the side faces of the valve manifold free for guards and control panels on food or packaging machinery by sending all working air out through the base floor.

speed

On-base speed tuning

Set cylinder speeds at each station with the built-in exhaust throttle - a hex-key turn clockwise slows the exhaust flow - replacing separate speed controllers in tight manifold rows.

FAQ

What do B and W mean on the ESV202MWB?

B places the PT1/4 working ports on the bottom of the manifold base (unused bottom ports are closed with plugs), and W centralizes the external pilot port so the whole run is fed from the 3M end plate, whose supply and exhaust ports are PT3/8. PT thread is standard; G thread is marked G.

What are the key figures of this base?

Mounting face ISO 5599-1; working ports PT1/4 (bottom); end-plate ports PT3/8; fluid air filtered by a 40 um element; proof pressure 1.5 MPa (215 psi); temperature -20 to +70 C; built-in exhaust throttle set with a hex key.
