Airtac ESV-M Base ESV202MWR
2. Mounting dimensions on connection surface compliant with ISO 5599-1 international standard;
3. Equipped with dedicated sealing components for enhanced flow capacity and extended service life;
4. 200/300/400 series enable conversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of seal assemblies;
5. Valve body requires base mounting, available in single-unit or modular multi-unit formats (multi-unit base allows flexible combination into arbitrary numbers);
6. Multiple air supply connection configurations and mounting options for optimized system integration;
7. 200/300/400 series bases integrate exhaust throttling functionality, eliminating need for external speed controllers.
Category: Solenoid Valve Base | Brand: AIRTAC | Series: ESV-M
AirTAC ESV-M Base ESV202MWR Technical Specifications
- Model: ESV202MWR
- Type: Modular valve manifold base (ISO 15407-2 compliant)
- Port configuration: 2-position manifold for ESV-M series valves
- Port size: 1/4" NPT (G1/8 optional)
- Max operating pressure: 0.9 MPa
- Voltage compatibility: Matches mounted solenoid valves (DC12V-AC220V)
- Weight: 320g ±5g
- Dimensions: 42mm(H) × 90mm(W) × 72mm(D)
- Body material: Reinforced PA66 with glass fiber
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 120℃ (with HNBR seals)
- Flow capacity: 700 NL/min (Cv=1.2)
- Mounting style: DIN rail or direct screw mounting
- Surface finish: Anti-corrosion anodized treatment
- Protection rating: IP67 when assembled with valves
Modular valve base engineered for high-density pneumatic systems, featuring integrated silencer and auto-venting design. The staggered port arrangement prevents tool interference during manifold assembly. Optimized flow channels reduce pressure drop by 18% compared to previous generations. Includes built-in pilot exhaust ports and standardized mounting slots for flexible configurations.
- Multi-station robotic welding cell manifolds
- Pharmaceutical blister packaging lines
- Semiconductor wafer handling equipment
- Beverage canning machine control clusters
- Automotive tire assembly systems
Installation protocol:
Apply 2.5-3.5 N·m torque during valve mounting. Use M4×12 stainless screws
for manifold stacking. Perform air tightness test at 0.6 MPa before operation.
| Property | Property Value |
|---|---|
| sku | ESV202MWR |
| Port Size | PT1/4 |
