AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV301MB

Genuine AirTAC iso valve base, order code ESV301MB from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartSingle base (1M)
  • Ports and pilotBottom ports (B)
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$24.41 $31.91Save 23%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV301MB

The ESV301MB is the bottom-port version of the ESV300 single base: the B in the order code moves the PT3/8 working ports from the side to the underside, so supply and exhaust lines come up from the mounting surface and stay clear of valves and fittings above the plate. It carries one ESV3x0 or EAV3x0 valve on its ISO 5599-1 face, exactly like any 1M base.

Where the B option places several ports on one face, the catalog notes that unused bottom ports are closed with plugs, so you order the base by the number of ports the chosen valve actually uses. The base keeps its independent external pilot port, and PT thread is standard - a G-thread installation must order the marked G variant.

Airtac ESV-M Base ESV301MB Technical Specifications

Order codeESV301MB
ProductISO Valve Base
PartSingle base (1M)
Ports and pilotBottom ports (B)
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

This code is defined by two choices. First, part type: 1M for one valve, while 2M manifold bases plus one 3M end plate set are for banks; expanding later means switching to a manifold. Second, port direction: ESV301M gives side PT3/8 ports and ESV301MB gives bottom ports, so pick the B version when piping enters from below the mounting plate and the side version when lines run along the frame.

The bottom arrangement also changes commissioning: because bottom ports not used by the valve are plugged, check the port count of your specific valve against the base before ordering, and remember that the pilot port remains independent regardless of the B option.

Applications

grid_view

Subplate-mounted valve on a machine base

Bolt the ESV301MB to a machine plate and route the PT3/8 air lines from below, keeping the valve top surface free for the ESV3x0 valve, its coil and manual overrides.

conveyor_belt

Conveyor section with under-floor piping

Air lines running through the conveyor frame reach the bottom PT3/8 ports directly, so no elbow fittings are needed above the mounting surface.

handyman

Compact actuator control block

A single ESV3x0 valve on the bottom-port 1M base drives one cylinder, with unused bottom ports closed by plugs to match the valve's actual port count.

FAQ

What are the key figures of the ESV301MB?

Single base (1M) with bottom (B) working ports in PT3/8, one ISO 5599-1 mounting face for an ESV3x0 or EAV3x0 valve, and an independent external pilot port. Unused bottom ports are closed with plugs. Proof pressure is 1.5 MPa (215 psi), temperature range is -20 to +70 C, fluid is air filtered by a 40 um element, and the exhaust throttle is built in (hex key, clockwise to reduce flow).

How does the ESV301MB differ from the ESV301M?

Only in port position: the blank code ESV301M puts the PT3/8 working ports on the side, while the B code ESV301MB puts them on the bottom. Both are 1M single bases for one valve with PT thread standard, so choose by where your piping enters - from below the plate or along the machine frame.
