AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV301MGB

Genuine AirTAC iso valve base, order code ESV301MGB from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartSingle base (1M)
  • Ports and pilotBottom ports (B)
  • Port threadG (BSPP)
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$24.41 $31.91Save 23%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV301MGB

A single 1M base from the AirTAC ESV300 series, built to carry exactly one ESV3x0 solenoid or EAV3x0 air-piloted valve on the standardized ISO 5599-1 mounting face. The G suffix gives you BSPP G threads on the working ports, and the B option moves those PT3/8 ports to the bottom of the base so tubing can drop straight down, away from the valve and coil area.

The exhaust throttle is built in: turn the adjusting screw with a hex key, clockwise to reduce exhaust flow, so no separate speed controller is needed on the cylinder side. The base is rated for 1.5 MPa (215 psi) proof pressure, works from -20 to +70 C on air filtered by a 40 um element, and carries an independent external pilot port that matters only for externally piloted valve versions.

Airtac ESV-M Base ESV301MGB Technical Specifications

Order codeESV301MGB
ProductISO Valve Base
PartSingle base (1M)
Ports and pilotBottom ports (B)
Port threadG (BSPP)
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Choose ESV301MGB over ESV301M when your piping standard is G (BSPP) rather than the PT default, and over ESV301MG when you want the ports underneath instead of on the side. If the machine will grow beyond one valve, move to the manifold family (ESV302M, ESV302MR, ESV302MB or ESV302MW) and finish each manifold with one ESV303M end plate set.

Applications

factory

Packaging machine valve drop

Bottom-working ports let PT3/8 G-thread tubing run down through the frame to the single ESV3x0 valve, keeping the coil and manual overrides clear at the ISO 5599-1 face.

build

BSPP retrofit panels

The G-thread suffix matches European BSPP piping without adapters, so an existing ISO 5599-1 valve can be re-seated on this single base during a panel rebuild.

settings

Exhaust speed tuning at the base

Use the built-in exhaust throttle, adjusted clockwise with a hex key to slow exhaust flow, to tune small actuator speeds without adding external speed controllers.

FAQ

What are the key figures of the ESV301MGB?

Single base (1M) for one valve, ISO 5599-1 mounting face, PT3/8 working ports in G (BSPP) thread located at the bottom (B), independent external pilot port, built-in exhaust throttle, 1.5 MPa (215 psi) proof pressure, -20 to +70 C, air filtered by a 40 um element.

Which valves can be mounted on it?

Any ESV3x0 solenoid valve or EAV3x0 air-piloted valve with the ISO 5599-1 mounting face. The independent external pilot port is only used when the fitted valve is an externally piloted version; internally piloted valves simply ignore it.
