AirTAC ESV300-BASE · ISO Valve Base

Airtac ESV-M Base ESV302M

Genuine AirTAC iso valve base, order code ESV302M from the ESV300-BASE range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • PartManifold base (2M)
  • Ports and pilotLeft ports · independent pilot
  • Port threadPT
  • PartsSingle base (1M), Manifold base (2M), End plate set (3M)
  • Working portsPT3/8
  • End-plate portsPT1/2
$31.39 $38.89Save 19%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ESV300-BASE part, ports and pilot and port thread on one page All ESV300-BASE codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ESV-M Base ESV302M

Order the ESV302M when one valve is not enough: this is the manifold base (2M) of the AirTAC ESV300 series, and you buy one per valve, bolting them together into a manifold of any number of stations. Every station presents PT3/8 working ports facing left, on the standard PT thread with no suffix needed in the order code.

Each station keeps its own independent external pilot port, so an externally piloted ESV3x0 or EAV3x0 valve is fed separately per station rather than from a shared line. The ISO 5599-1 face takes ESV3x0 solenoid and EAV3x0 air-piloted valves, and the built-in exhaust throttle is turned clockwise with a hex key to reduce exhaust flow at each station.

Airtac ESV-M Base ESV302M Technical Specifications

Order codeESV302M
ProductISO Valve Base
PartManifold base (2M)
Ports and pilotLeft ports · independent pilot
Port threadPT
PartsSingle base (1M), Manifold base (2M), End plate set (3M)
Working portsPT3/8
End-plate portsPT1/2
Mounting faceISO 5599-1
FluidAir (filtered by 40 µm element)
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
Exhaust throttleBuilt in

Source: AirTAC Products Catalog 2026A (PDF01-P0094..P0096), ESV200/300/400/600 series specifications and ordering code.

How to choose

Among the manifold bases, the plain ESV302M delivers working ports from the left. Pick ESV302MR if the valves face the ports to the right, ESV302MB if piping should drop below the base, and ESV302MW to replace the independent pilot with a centralized external pilot supply. For G (BSPP) piping add the G suffix, and close every manifold with one ESV303M end plate set, whose ports are one size larger at PT1/2.

Applications

conveyor_belt

Multi-station conveyor control

Bolt one 2M base per directional valve along the conveyor, then cap the assembly with an ESV303M end plate set to close the shared supply and exhaust.

factory

Clamping fixtures with per-station pilots

The independent external pilot port feeds each externally piloted valve separately, useful where stations must stay isolated from a shared pilot circuit.

settings

Cylinder speed control at the manifold

Turn each station's built-in exhaust throttle clockwise with a hex key to meter exhaust flow, avoiding extra speed controllers in already-crowded cabinets.

FAQ

What are the key figures of the ESV302M?

Manifold base (2M), one per valve, ISO 5599-1 mounting face, PT3/8 working ports on the left in PT thread, independent external pilot port per station, built-in exhaust throttle, 1.5 MPa (215 psi) proof pressure, -20 to +70 C, air filtered by a 40 um element.

How is a manifold built and closed off?

Use one 2M base per valve and bolt them into any number of stations, then add one end plate set (order code ESV303M) per manifold. The end plate's supply and exhaust ports are one size larger than the working ports, at PT1/2.
